Sensor Size (W x H)
Full Frame Format 38.1x20.1
Key Features
Full Frame Sensor
5.9K Canon RAW
ProRes Recording
Anamorphic Support
S35/S16 Sensor Modes
Lens Mount
PL Mount Locking
EF Mount (Mount change via service centre)
RAW Recording Feature
(Internal / External)
Canon RAW 5.9K @50/60P (10/12 bit)
*Requires Codex CDX-31650
Highest Quality Compressed Recording Codecs
(Bit Depth / Data Rates)
*@50P unless otherwise stated
XF-AVC: 4096 x 2160 YCC422 (10 bit/810Mbps Intra)
ProRes 422HQ: 4096 x 2160 YCC 422 (10 bit)
XF-AVC (Proxy): 2048 x 1080 YCC 420 (8 bit/35Mbps Long GOP)
Media Type
Cfast (Dual Slots)
SD Card
Codex Drive (For use with Codex Recorder only)
Battery Type
(Power Consumption)
V Mount Block Battery
SDI Output Specifications
(SDI Out only)
4 X 3G SDI (4096 x 2160) (YCC 422 10 bit)
Input / Output Configuration
HDMI out, Headphone Jack, Mic Jack, Genlock, Sync Out, TC (In/Out), Mon 1 & 2, Remote A, Remote B, Video, Lens, RJ45, XLR x 2, CTRL, DC In 12V 2A(Fischer), DC Out 12V 2A(Lemo), D-Tap out (50W)
LCD Screen and EVF Specifications
EVF-V70 (Sold Seperately)
Base ISO (Clog 2 & 3)
800
Dimensions (W x H x D)
*Weight (Body only)
Dimensions: 167 x 154 x 327
Weight: 3455g
Additional Notes
Full fledged Cinema cameras with comprehensive I/O choices.
